新一代羅茨真空泵技術(shù)參數(shù)：
| 型號 Model | 極限壓力 Ultimate Pressure | 抽氣速率Pumping Speed (L/s) | 進氣口徑 Inlet Diam (mm) | 排氣口徑 Outlet Diam (mm) | 配用功率 Motor Power (kW) | 冷卻水量 Cooling Water Consumption (kg/h) | 轉(zhuǎn)速 Speed (50/60Hz) RPM | |
| Pa | Torr | |||||||
| BH-30GK | 0.6 | 4.5×10-3 | 30 | 50 | 73 | 3.00 | 風(fēng)冷 | 250 |
| BH-50GK | 0.6 | 4.5×10-3 | 50 | 80 | 73 | 4.00 | 100 | 335 |
| BH-80GK | 0.6 | 4.5×10-4 | 80 | 80 | 80 | 7.50 | 150 | 580 |
| BH-150GK | 0.6 | 4.5×10-3 | 150 | 100 | 100 | 11.0 | 200 | 825 |
| BH-180GA | 1.0 | 7.5×10-3 | 180 | 160 | 100 | 15.0 | 450 | 1155 |
| BH-200GA | 1.0 | 7.5×10-3 | 200 | 160 | 100 | 15.0 | 450 | 1155 |
| BH-230GA | 1.0 | 7.5×10-3 | 230 | 160 | 100 | 18.5 | 450 | 1175 |
| BH-300GA | 1.0 | 7.5×10-3 | 300 | 160 | 100 | 22.0 | 700 | 1525 |
| BH-150GF | 1.0 | 7.5×10-3 | 150 | 100 | 100 | 11.0 | 200 | 905 |
| BH-200GF | 1.0 | 7.5×10-3 | 200 | 160 | 100 | 15.0 | 450 | 1255 |
| BH-300GF | 1.0 | 7.5×10-3 | 300 | 160 | 100 | 22.0 | 700 | 1650 |
